Little Giant Water Wizard Submersible Pump 505486
LITTLE GIANT Water Wizard Submersible Pump
Little Giant 505486 Water Wizard Submersible Pump
- Motor – 1/6HP Shaded Pole
- Maximum flow rate – 1200 GPH @ 1′, 4542 LPH @ 30 cm.115V, 60Hz, 5 amps
- Maximum Head – 26.3″…8 m
- Intermittent Liquid Temp to – 120° F….49° C
- Epoxy-coated aluminum housing
- Operates submersed1″FNPT (25.4 mm) discharge
- 1″ FNPT outlet includes garden-hose adapter, bottom inlet has removable screen for easy cleaning
Little Giant 1/4 Horsepower Sump Pump 505700
LITTLE GIANT 1/4 Hp Sump Pump
Little Giant 505700 1/4 Horsepower Sump Pump
- 1/4 HP
- 1-1/4″ FNPT outlet with a garden hose adapter
- 10′ or 25′ length power cords are available
- Integral snap-action float switch
- Automatic operation has 7″-10″ .ON. level range and 2″-5″ .OFF. level range
- Thermally protected3/8″ solid handling capacity
Little Giant Drainosaur Water Pump System 506055
Little Giant 506055 Drainosaur Water Pump System
- Pump made of cast iron housing with protective epoxy coating for corrosion resistance
- Screened intake
- 1/3 HP motor with thermal overload protection
- Automatic diaphragm pressure switch enclosed in nylon housing with .on. level at 7″.10″ and .off. level at 1″.4″
- Basin made of polypropylene
Little Giant Big John Sump Pump 506158
Little Giant 506158 Big John Sump Pump
- Cast iron pump housing with protective epoxy coating for corrosion resistance
- Oil-filled motor housing for lifetime lubrication and rapid heat dissipation
- 1/3 HP shaded pole motor
- Stainless steel screws, bolts and handle to protect against corrosion
- Mechanical seal (stainless steel spring, nitrile parts, carbon and ceramic faces) to assure maximum protection against pump failure
- Bearings: Upper and lower sintered sleeve bearings for extended motor life
- Thermal overload protection
Little Giant Pit Plus Simplex 509109
Little Giant 509109 Pit Plus Package with Foam Cover
The Little Giant PitPlus™ comes equipped with a 4/10 HP 9S Series or a 1/2 HP 10S Series wastewater and sewage ejector pump. Both units are equipped with cast iron housings and volutes that have a protective epoxy coating. Automatic operation is achieved by use of a piggyback mechanical float switch.
Features:
- 4/10 HP 9S Series pump
- Handles liquid and solid waste materials up to 2″ diameter
- Larger capacity extends pump life by reducing pump cycles
- 20″×30″ polyethylene basin with ribs for added strength
- 4″ molded external inlet hub to accept flexible coupling
- Molded torque stops in bottom of basin to locate and secure pump
- Anti-flotation collar
- Stainless steel cover bolts
Little Giant Simplex Basin 513240
Little Giant 513240 Simplex Basin and Cover
- Basins available in molded polyethylene or fiberglass
- Complete with necessary sealing hardware and flanges
- Available with 2″ or 3″ vent or discharge flange
- 4″ inlet hub is included with the basin
- Water tight and gas tight when properly installed
- Durable steel gasketed cover standard on fiberglass basin, structural foam cover on poly basin
- One-piece, seam-free construction on basin
- Ready-to-install for simple and economical installation
- Temperature rated up to 130°F
Little Giant 547151 Big John Vertical Sump/Effluent Pump
Little Giant 547151 Big John Vertical Sump/Effluent Pump
- Plastic volute made of corrosion-proof ABS
- 1-1/4″ FNPT discharge
- 1/4″ solids handling capability
- Thermal overload protection
- Automatic operation with integral snap-action float switch
- Adjustable on/off levels: on 10″. 5″, off 9″. 4″
- UL/CSA listed
Little Giant 554200 115V 60Hz Condensate Removal Pump
Little Giant 554200 115V 60Hz Condensate Removal Pump
- Low profile compact size
- Vertical type pump unit
- Leakproof, rustproof, ABS tank
- Stainless steel motor shaft
- 3/8″ O.D. barbed discharge adapter
- Built-in check valve
- Safety switch included
- 20′ shut-off head
- 6′ power cord
- UL/CSA listed
Little Giant 554550 Condensation Removal Pump
Little Giant 554550 Condensation Removal Pump
- 1/4 turn check valve allows servicing without removal of tubing, eliminating water spills
- Patent-pending cooling design increases pump life
- Optional external overflow safety switch, which gives the option to connect air-handler shutdown or activate an alarm or building automation system
- External test/run lever for quick and easy drainage of tank for servicing
- Oil-resistant tank and check valve eliminates the problem of cracked tanks with exposure to oil
- Rubber feet absorb vibration on hard surface installations
- 1/4 turn check valve allows servicing without removal of tubing, eliminating water spills
- Patent-pending cooling design increases pump life
Little Giant Pond Waterfall Pump 566407
Little Giant 566407 Waterfall/Stream Pump 4300 GPH
4300 GPH* Ideal for use in waterfall and stream applications, this powerful direct-drive pump features a unique dual-discharge design for operation of two water features simultaneously. This pump is extremely versatile, able to be used vertically or horizontally.
